Acoustic Emission (AE) System

MTEU3H 4 Channels AE DAQ
10 MHz sample rate 16bit resolution 1GB DDR

MTAE Software
AE signal real-time acquisition, data analysis and replay analysis.
Friendly interface, simple operation
Powerful digital filtering function
High degree of customization, various acquisition configuration
and visualization of AE parameters and waveform.
Various 3D positioning diagram display, linear, planar, cube,
cylinder, tank bottom, sphere location etc.
FFT, wavelet, intensity and activity, clustering analysis etc.

MT40 AE Sensor with Built-in Pre-Amp
Frequency Range 15KHz to 65KHz
Resonant Frequency 50kHz

MT150 AE Sensor with Built-in Pre-Amp
Frequency Range 60kHz to 390kHz
Resonant Frequency 150kHz
